An estimated 75% of CIS devices produced today are used in smart phone cameras. With the latest smart phones incorporating multiple cameras, CIS production is forecasted to grow approximately 41% over the next four years, according to an Advantest study. In addition, the latest CIS devices have high resolution on the order of 100 million pixels.  These factors increase demand for test solutions that can handle larger volumes of data than ever before while operating at higher speeds to cost-effectively serve the rapidly expanding smart phone market.

The 4.8GICAP module, combined with Advantest’s 3rd generation IPE, can simultaneously capture images and transfer data to the IPE using a two-bank memory mechanism. This will significantly reduce test time.

The unit is designed for installation on the T2000 ISS tester with a fully compatible test program, prober, light source and device interface. This combination produces CIS measurement tools capable of 64-site parallel testing, which supports latest C-PHY in addition to the MIPI standard D-PHY. The new module delivers industry-leading performance with high-speed transmission lines.

The versatile T2000 test platform enables users to respond quickly to shifting market needs with minimal capital investment while also helping to reduce development times for new designs. Its modular architecture is ideally suited to accommodate new generations of devices.

“By providing a measurement environment that can handle greater data-transfer volumes and faster CIS devices, we are bringing improved cost efficiencies to the smart phone camera market,” said Toshiaki Adachi, vice president of the T2000 Business Unit at Advantest.

The 4.8GICAP module has begun shipping to several key customers.For more information on the T2000 test platform, visit https://www.advantest.com/products/ic-test-systems/t2000.
